cMT-SVRX 820 Headless HMI, Quad-core, 4GB Flash, dual LAN.

CMT SVRX 820

Feature
• Compact Design and DIN-rail Mountable
• Fan-less Cooling System
• Built- in 256 MB Flash Memory and RTC
• SD Card Slot for Expansion of Storage
• One USB Host Port
• Two Gigabit Ethernet Ports
• Supports E-mail
• Supports MPI 187.5K*
• Built-in Power Isolator

SpesifikasiUSB ClientN/ACOM2: RS-485 2W/4WPower Consumption230mA@24VDCDimensions WxHxD27 x 130 x 115 mmOperating Temperature-20° ~ 55°C (32° ~ 131°F)

Memory	Flash	256MB
Memory	RAM	256MB
Processor		32-bit RISC 600MHz
I/O Port	Micro SD Card Slot	SD/SDHC
	USB Host	USB 2.0 x 1
	Ethernet	10/100/1000 Base-T x 2
	COM Port	COM1: RS-232 2W
		COM3: RS-485 2W
		RS-485 Dual Isolation	N/A
	CAN Bus	N/A
	HDMI Output	N/A
	Audio Output	N/A
	RTC		Built-in
	Power	Input Power	24±20%VDC
Power Isolation		Built-in
Voltage Resistance		500VAC (1 min.)
Isolation Resistance		Exceed 50MΩ at 500VDC
Specification		PCB Coating	Yes
	Enclosure	Plastic
	Weight	Approx. 0.18 kg
	Mount	35mm DIN rail mounting
	Environment	Protection Structure	IP20
Storage Temperature		-20° ~ 70°C (-4° ~ 158°F)
Relative Humidity		10% ~ 90% (non-condensing)
Vibration Endurance		10 to 25Hz (X, Y, Z direction 2G 30 minutes)
Certificate		CE	ce Marked
Certificate	UL	cULus Listed
Software	EasyBuilder Pro	V4.00.01 or later versions
Software	Weincloud	EasyAccess 2.0 (Optional)
